EQ 100M

Description

This unit comes with a hot-dipped galvanized blast pot – integral hand truck assembly; stainless steel control panel, plumbing and components, along with a 10-gallon, UV-protected poly water tank. The EQ100M, when coupled with any air compressor capable of producing 185~350 cfm @ 100+ psi has the ability to blast from 30~130 psi. The EQ100M comes standard with 50 feet of blast hose, pneumatic or electric dead man control, a #7 nozzle, and a low tank water shut-down system. The unit can be loaded into a pickup truck using the slide-rails to assist, or by using the lifting eye. It can be stowed or moved while on its back utilizing the two additional rollers at the handle.

  • Holds 250lbs of abrasive
  • Fully portable design with slide-rails
  • Uses standard 185cfm compressor
  • Utilizes any abrasive heavier than water

Specifications

  • Dimensions: 33.75”L x 25” W x 46” H
  • Weight: 360 lbs. Dry / 550 lbs. Wet
  • Air Capacity 165-350 CFM
  • Pot Media Capacity 250bs
  • Hose Length 50ft. Standard Blast Hose
  • Available: Accessories Hose Extensions, Extension Wands & Nozzles
  • Warranty: Complete Machine for 1 Year From Original Purchase Date (necessary PM items excluded)

Benefits

  • Reduced Media Consumption (50-150 lbs of media an hour)
  • Reduced Run-Off (Less than 1 qt per minute)
  • Suppresses up to 97% of airborne particles (Lowering containment cost)
  • Less waste material to dispose (Reducing transport and disposal cost)
  • Effective in rain and high humidity
  • Remove coatings w/o damaging sub-surface
  • Standard Abrasive Grit heavier than water*

* For the best production use performance media with a medium to fine mesh size.
** Please see complete warranty for details. Specification subject to change without notice.
